Solar Charge Controller
MPPT solar controller 10A-150A
Product Specification:- Brand Name : TANFON SOLAR
- Model Number : solar inverter 5kw
- DC voltage : 48V
- Output voltage : 110V/220V
- Advantage : German Technology
You May Like
- 192V/360V/384V Intelligent solar controller power generation display.
- Have stronger IGBT module PV off-grid inside
- IGBT modularization to reduce the failure rate and improve service life
- Industrial-grade chips ensure stable performance
- Advanced battery activation technology keep full capacity
- Three charging stages: Fast charging, equalize charging and float charging
- It has the function of generating capacity display
- Can display the daily generating, monthly generating and total generating
- Have Large LCD screen simulation display and touching key
|
Model |
HP192/100A Electrical Parameter |
|
|
Rated system voltage |
192V |
|
|
Max. input voltage |
400V |
|
|
Rated charging current |
100A |
|
|
No. of input |
1 group |
|
|
No-load loss |
<0.5W |
|
|
Equalize voltage |
230.4V |
Adjustable |
|
Equalize recovery voltage |
220.8V |
|
|
Equalize charging time |
120 Minutes |
|
|
Float voltage |
211.2V |
|
|
Over voltage disconnect |
256.0V |
|
|
Over voltage reconnect |
240.0V |
|
|
Environment Parameter |
||
|
Display |
3’’ LCD (White backlight) |
|
|
Display language |
English |
|
|
Indicator light |
Error indicator/Charging indicator |
|
|
Terminal type |
TC Series barrier terminal |
|
|
Humidity |
0~98%, non-condensing |
|
|
Environment temperature |
-25°C +55°C |
|
|
Elevation |
≤4000M, should reduce power if the elevation high than 4000M |
|
|
Protection level |
IP32 |
|
|
Noise |
<30dBA |
|
|
Dimension |
420*345*157mm |
|
|
Weight |
12KG |
|
|
Package information |
Hard box with pearl sponge |
|
