On Grid Solar Inverter
on grid solar inverter 17kw 18kw 19kw hybrid inverter in Martinique
Product Specification:- Brand Name : TANFON
- Model Number : HBF17K-HBF19K
- Output Power : 1kw-19kw
- Output Type : Single
You May Like
Description of this PV on-grid inverter
- Real time monitors inverters remotely by data logger
- Multilingual support available
- Efficient non-isolated topological structure
- Temperature range -25’C to 60’C, Compact design, easy to install
Performance Feature
- Controlled by TI Digital DSP
- Controlled by high efficient MPPT to track the maximum PV output, MPPT rate >99%
- Pure sine wave output, automatic synchronization to grid, low harmonics
- Anti-island protected by disturbance detection
- Excellent functions of protection and alarm
- Optional CAN, Ethernet, RS485, Bluetooth ports and remote data collection
Working circuit diagram
PV on-grid inverter
Specification
|
|
Item |
HBF1K |
HBF2K |
HBF3K |
|
Delivery period (Week) |
4 |
4 |
4 |
|
|
Type |
Outdoor |
Outdoor |
Outdoor |
|
|
Input DC |
Max DC power |
1.9KW |
2.8KW |
3.9KW |
|
Max. DC input voltage |
450V |
450V |
5000V |
|
|
MPP voltage range |
90-450V |
100-500V |
100V-500V |
|
|
Rated input voltage (V) |
360V |
360V |
360V |
|
|
Maximum input current |
10A |
15A |
15A |
|
|
Number of MPPT inputs |
1 |
1 |
1 |
|
|
Number of DC inputs |
1 |
1 |
1 |
|
|
Output AC |
Rated power |
1KVA |
2KVA |
3KVA |
|
Rated AC voltage |
120/230V |
120/230V |
120/230V |
|
|
Rated frequency (Hz) |
50Hz/60Hz |
50Hz/60Hz |
50Hz/60Hz |
|
|
Max. output current (A) |
7A |
12A |
13A |
|
|
THD (rated power) |
<2% |
<2% |
<2% |
|
|
Power factor at rated power |
≥0.99 |
≥0.99 |
≥0.99 |
|
|
Connection phases |
Single-phase |
Single-phase |
Single-phase |
|
|
Efficiency |
Max. efficiency |
97.40% |
97.40% |
97.40% |
|
European efficiency |
96.70% |
96.70% |
96.70% |
|
|
Protection |
Input-side disconnection device |
no |
no |
no |
|
Output-side disconnection device |
no |
no |
no |
|
|
Grid monitoring |
● |
● |
● |
|
|
Ground fault monitoring |
● |
● |
● |
|
|
Insulation monitoring |
● |
● |
● |
|
|
Electrical isolation |
no |
no |
no |
|
|
Physical |
Dimensions (W) (mm) |
405*314*135 |
405*314*135 |
405*314*135 |
|
Package |
3800/40HQ |
3800/40HQ |
3800/40HQ |
|
|
Weight (Kg)/per unit |
17 |
17 |
17 |
|
|
Weight (Kg)/per 40HQ |
64600 KGS |
64600 KGS |
64600 KGS |
|
|
Operating temperature range (℃) |
-25~+60 |
-25~+60 |
-25~+60 |
|
|
Max self-consumption |
20W/0W |
20W/0W |
20W/0W |
|
|
Cooling concept |
Self- cooling |
Self- cooling |
Self- cooling |
|
|
Degree of Protection |
IP65 |
IP65 |
IP65 |
|
|
Application |
Relative humidity range (non-condensation) |
0~95% |
0~95% |
0~95% |
|
Max operating altitude above MSL |
2000 m |
2000 m |
2000 m |
|
|
Feature |
Display |
LCD |
LCD |
LCD |
|
Communication interface |
RS485 |
RS485 |
RS485 |
|
|
Certification |
CE |
CE |
CE |
|
|
Item |
HBF4K |
HBF5K |
HBF6K |
|
Delivery period (Week) |
1 |
1 |
1 |
|
|
Type |
Outdoor |
Outdoor |
Outdoor |
|
|
Input DC |
Max DC power |
4.4KW |
5.5KW |
6.6KW |
|
Max. DC input voltage |
550v |
600v |
600v |
|
|
MPP voltage range |
90V-580V |
|||
|
Rated input voltage (V) |
360V |
360V |
360V |
|
|
Maximum input current |
20A |
20A |
20A |
|
|
Number of MPPT inputs |
2 |
2 |
2 |
|
|
Number of DC inputs |
1 |
1 |
1 |
|
|
Output AC |
Rated power |
4KVA |
5KVA |
6KVA |
|
Rated AC voltage |
120/230V |
120/230V |
120/230V |
|
|
Rated frequency (Hz) |
50Hz/60Hz |
50Hz/60Hz |
50Hz/60Hz |
|
|
Max. output current (A) |
20A |
25A |
25A |
|
|
THD (rated power) |
<2% |
<2% |
<2% |
|
|
Power factor at rated power |
≥0.99 |
≥0.99 |
≥0.99 |
|
|
Connection phases |
Single-phase |
Single-phase |
Single-phase |
|
|
Efficiency |
Max. efficiency |
97.40% |
97.40% |
97.40% |
|
European efficiency |
96.30% |
96.30% |
96.30% |
|
|
Protection |
Input-side disconnection device |
no |
no |
no |
|
Output-side disconnection device |
no |
no |
no |
|
|
Grid monitoring |
● |
● |
● |
|
|
Ground fault monitoring |
● |
● |
● |
|
|
Insulation monitoring |
● |
● |
● |
|
|
Electrical isolation |
no |
no |
no |
|
|
Physical |
Dimensions (W) (mm) |
478*344*170 |
478*344*170 |
478*344*170 |
|
Weight (Kg)/per unit |
16.8 |
16.8 |
16.8 |
|
|
Operating temperature range (℃) |
-25~+60 |
-25~+60 |
-25~+60 |
|
|
Max self-consumption |
20W/0W |
20W/0W |
20W/0W |
|
|
Cooling concept |
Forced cooling |
Forced cooling |
Forced cooling |
|
|
Degree of Protection |
IP65 |
IP65 |
IP65 |
|
|
Application |
Relative humidity range (non-condensation) |
0~95% |
0~95% |
0~95% |
|
Max operating altitude above MSL |
2000 m |
2000 m |
2000 m |
|
|
Feature |
Display |
LCD |
LCD |
LCD |
|
Communication interface |
RS485 |
RS485 |
RS485 |
|
|
|
Item |
HBF10K |
HBF15K |
HBF20K |
|
Delivery period (Week) |
1 |
1 |
1 |
|
|
Type |
Outdoor |
Outdoor |
Outdoor |
|
|
Input DC |
Max DC power |
10.4KW |
15.6KW |
20.6KW |
|
Max. DC input voltage |
1000v |
1000v |
1000v |
|
|
MPP voltage range |
160V-960V |
250V-960V |
250V-960V |
|
|
Rated input voltage (V) |
600V |
600V |
600V |
|
|
Maximum input current |
24A |
42A |
42A |
|
|
Number of MPP inputs |
2 |
2 |
2 |
|
|
Number of DC inputs |
2 |
2 |
2 |
|
|
Output AC |
Rated power |
10KVA |
15KVA |
20KVA |
|
Rated AC voltage |
220/380V |
380V |
380V |
|
|
Rated frequency (Hz) |
50Hz/60Hz |
50Hz/60Hz |
50Hz/60Hz |
|
|
Max. output current (A) |
16.1A |
24.2A |
31A |
|
|
THD (rated power) |
<2% |
<2% |
<2% |
|
|
Power factor at rated power |
≥0.99 |
≥0.99 |
≥0.99 |
|
|
Connection phases |
Three-phase |
Three-phase |
Three-phase |
|
|
Efficiency |
Max. efficiency |
97.40% |
97.40% |
97.40% |
|
European efficiency |
96.30% |
96.30% |
96.30% |
|
|
Protection |
Input-side disconnection device |
no |
no |
no |
|
Output-side disconnection device |
no |
no |
no |
|
|
Grid monitoring |
● |
● |
● |
|
|
Ground fault monitoring |
● |
● |
● |
|
|
Insulation monitoring |
● |
● |
● |
|
|
Electrical isolation |
no |
no |
no |
|
|
Physical |
Dimensions (W) (mm) |
483*452*200 |
709*452*246 |
709*452*246 |
|
Weight (Kg)/per unit |
22 |
45 |
45 |
|
|
Operating temperature range (℃) |
-25~+60 |
-25~+60 |
-25~+60 |
|
|
Max self-consumption |
20W/0W |
20W/0W |
20W/0W |
|
|
Cooling concept |
Forced cooling |
Forced cooling |
Forced cooling |
|
|
Degree of Protection |
IP65 |
IP65 |
IP65 |
|
|
Application |
Relative humidity range (non-condensation) |
0~95% |
0~95% |
0~95% |
|
Max operating altitude above MSL |
2000 m |
2000 m |
2000 m |
|
|
Feature |
Display |
LCD |
LCD |
LCD |
|
Communication interface |
RS485 |
RS485 |
RS485 |
|
|
Item |
HBF30K |
HBF50K |
HBF100K |
|
Delivery period (Week) |
1 |
1 |
1 |
|
|
Type |
Outdoor |
Outdoor |
Indoor |
|
|
Input DC |
Max DC power |
31KW |
52KW |
110KW |
|
Max. DC input voltage |
1000v |
1000v |
1000v |
|
|
MPP voltage range |
250V-960V |
250V-960V |
480V-960V |
|
|
Rated input voltage (V) |
600V |
600V |
600V |
|
|
Maximum input current |
42A |
42A |
42A |
|
|
Number of MPP inputs |
2 |
2 |
2 |
|
|
Number of DC inputs |
4 |
4 |
4 |
|
|
Output AC |
Rated power |
30KVA |
50KVA |
100KVA |
|
Rated AC voltage |
220/380V |
220/380V |
220/380V |
|
|
Rated frequency (Hz) |
50Hz/60Hz |
50Hz/60Hz |
50Hz/60Hz |
|
|
Max. output current (A) |
16.1A |
24.2A |
31A |
|
|
THD (rated power) |
<2% |
<2% |
<2% |
|
|
Power factor at rated power |
≥0.99 |
≥0.99 |
≥0.99 |
|
|
Connection phases |
Three-phase |
Three-phase |
Three-phase |
|
|
Efficiency |
Max. efficiency |
97.40% |
97.40% |
97.40% |
|
European efficiency |
96.30% |
96.30% |
96.30% |
|
|
Protection |
Input-side disconnection device |
no |
no |
no |
|
Output-side disconnection device |
no |
no |
no |
|
|
Grid monitoring |
● |
● |
● |
|
|
Ground fault monitoring |
● |
● |
● |
|
|
Insulation monitoring |
● |
● |
● |
|
|
Electrical isolation |
no |
no |
no |
|
|
Physical |
Dimensions (W) (mm) |
767*564*291 |
767*564*291 |
737*713*297 |
|
Weight (Kg)/per unit |
68 |
70 |
125 |
|
|
Operating temperature range (℃) |
-25~+60 |
-25~+60 |
-25~+60 |
|
|
Max self-consumption |
20W/0W |
20W/0W |
20W/0W |
|
|
Cooling concept |
Forced cooling |
Forced cooling |
Forced cooling |
|
|
Degree of Protection |
IP65 |
IP65 |
IP65 |
|
|
Application |
Relative humidity range (non-condensation) |
0~95% |
0~95% |
0~95% |
|
Max operating altitude above MSL |
2000 m |
2000 m |
2000 m |
|
|
Feature |
Display |
LCD |
LCD |
LCD |
|
Communication interface |
RS485 |
RS485 |
RS485 |
On grid inverter price list:
|
MODEL |
PRICE(USD) |
PRICE(USD) |
|
HBF1K(60V-420V) |
USD550(110V) |
USD303(220V)single phase |
|
HBF2K(60V-420V) |
USD572(110V) |
USD320(220V)single phase |
|
HBF3K(260V-420V) |
USD715(110V) |
USD340(220V)single phase |
|
HBF4K(260V-420V) |
USD953(110V) |
USD395(220V)single phase |
|
HBF5K(260V-420V) |
USD965(110V) |
USD410(220V)single phase |
|
HBF6K(260V-420V) |
USD989(110V) |
USD422(220V)single phase |
|
HBF10K(380V-800V) |
USD753(380V) |
USD1680(220V)three phase |
|
HBF15K(380V-800V) |
USD974(380V) |
USD2520(220V)three phase |
|
HBF20K(468V-800V) |
USD1102(380V) |
USD2668(220V)three phase |
|
HBF30K(468V-800V) |
USD1507(380V) |
USD4123(220V)three phase |
|
HBF50K(468V-800V) |
US1893(380V) |
USD5648(220V)three phase |
|
HBF100K(468V-800V) |
USD3787(380V) |
USD14926(220V)three phase |
Remark:
1) All price are FOB foshan sample price ,discount base on the quantity
2)Payment term:T/T full in advance for sample order .quantity order can accept OEM
3)Warranty :5 years.during the warranty ,will ship the free parts for after sales service .
4)Delivery time :sampel for 3-7 days.
5)50pcs or more:need 15 days.
6)after sales service:during the warranty ,ship the free PCB parts for service
On grid Inverter picture
|
|
|
