FOSHAN TANFON ENERGY TECHNOLOGY CO.,LTD
Solar Panel
HOME/Solar Panel

Solar Panel

High Power 500 Watt Solar Panel 48V PV Modules

Product Specification:
  • Brand Name : TANFON
  • Model Number : FS500M
  • Warranty : 25-Year
Inquiry Now
Product Details
One-stop service
Customer Feedback

500 Watt Solar Panel



500 Watt Solar Panel

Tanfon solar panel advantages:

1. IP68 Junction Box, Connector

2. 15A current

3. Super strong frame

4. Current division

5. Salt spray, Ammonia and PID test

6. Strong Mechanical load capacity

7. Color Classification



Tanfon 450~500 Watt Mono solar panel

Moduel

FS450M

FS460M

FS470M

FS480M

FS490M

FS500M

Rated Maximum

Power at STC

450W

460W

470W

480W

490W

500W

Open Circuit Voltage(Voc/V)

58.57V

58.71V

58.83V

58.89V

58.91V

58.95V

Maximum Power Voltage(Vmp/V)

47.88V

48.01V

48.23V

48.45V

48.45V

48.63V

Short Circuit Current(Isc/A)

9.73A

9.78A

9.86A

10.04A

10.67A

10.87A

Maximum Power Current(Imp/A)

9.4A

9.59A

9.75A

9.93A

10.12A

10.28A

Power Tolerance

0 ~ +3%

Standard Test Condition(STC)

1000W/m2 irradiance, 25°C cell temperature, AM1.5





 500 watt solar panel



500 watt solar panel



500 watt solar panel

500 watt solar panel

Products have been sold to more than 130 countriesImportantly, we have one professional installation team, has been to 32 countries and regions for installation service as well as win good feedback from the customers.

Tanfon 2 set of 200kw solar system in Papua New Guinea

500 watt solar panel

1.2MW mono photovoltaic solar panels roof grid tie project

500 watt solar panel

500 watt solar panel





500 watt solar panel

500 watt solar panel

500 watt solar panel

We accept OEM and small trial orders, contacting with us now for more information. All inquiries will be replied with in 24 hours.

SOLAR POWER SYSTE ALL PARTS: CABLE, SOLAR RACKING, SOLAR INVERTER WITH CONTROLLER, BATERY
